2021 Subaru Forester Wiper Sizes, Bulb Sizes & Tire Sizes
The short answer
The 2021 Subaru Forester takes 26" driver and 17" passenger wiper blades (rear 14"), has sealed LED headlights with no replaceable low-beam bulb, and rides on 225/60R17 tires as standard (Base, Premium); Sport and Limited and Touring use 225/55R18.
Wiper blade sizes
Tire sizes by trim
Base, Premium (standard)
225/60R17 99H · 33 front / 32 rear psi See tires at Amazon
Sport, Limited, Touring
225/55R18 98H · 35 front / 33 rear psi See tires at Amazon
The size on the placard inside the driver's door jamb is the one your car left the factory with. Match that, not this table, if they differ; a previous owner may have changed wheels.
Bulb sizes
Low beam
Sealed LED, no replaceable bulb
High beam
Sealed LED, no replaceable bulb
Fog light
H16 Shop on Amazon
Daytime running
Sealed LED, no replaceable bulb
Front turn signal
7444NA Shop on Amazon
Rear turn signal
7440A Shop on Amazon
Brake light
Sealed LED, no replaceable bulb
Tail light
Sealed LED, no replaceable bulb
Reverse light
921 Shop on Amazon
License plate
Sealed LED, no replaceable bulb
Wheel specs and lug torque
Bolt pattern
5x114.3 mm (5x4.5")
Center bore
56.1 mm
Lug thread
M12x1.25 Shop on Amazon
Lug nut torque
89 ft-lbs (121 Nm)
Factory wheel sizes
17x7, 18x7
Key fob, battery and sensors
Key fob battery
CR2032 Shop on Amazon
Replacement fob
FCC ID HYQ14AHK · part 88835FL03A · 4-button · smart key Shop on Amazon
Frequency
433 MHz
Relearn
tool
Roof rack and roof load
Roof load limit
176 lb (80 kg), evenly spread, while driving
Rack mounting
Raised side rails Shop crossbars on Amazon
Dimensions, weight and fuel
Length
182.1" (463 cm)
Width
71.5" (182 cm)
Height
68.1" (173 cm)
Wheelbase
105.1" (267 cm)
Ground clearance
8.7" (22 cm)
Fuel
Gasoline
Octane
87 (regular)
Fuel tank
16.6 gal (63 L)
Worth knowing about the 2021 Forester
- Wipers. Rain-X lists these front arms as a special wet-arm push-button type, so choose blades listed for this model rather than by length alone.
- LED lighting. The low beam, high beam, daytime running, brake light, tail light, license plate are sealed LED units with no user-replaceable bulb. A failure means replacing the assembly.
- Bulbs. The H16 fog bulb applies to halogen fog lights; LED fog lights are sealed units.
- Spare. This vehicle carries a compact (temporary) spare.
- Tire chains. The manual says not to fit tire chains on this vehicle; wheel-well clearance is too tight.
- Tires. The manual says tire chains cannot be used, and a non-chain SAE Class S traction device goes on the front wheels only if its maker recommends it, and the compact spare is a T145/80D17.
- Torque. Tighten lug nuts to 89 ft-lbs in a star pattern with a torque wrench, and re-check after the first 50 miles. This figure is from the owner's manual; an impact gun will overshoot it.
- TPMS. New sensors on this car need a relearn (tool); they will not pair on their own by driving.
- Key fob. Match the FCC ID (HYQ14AHK) printed on the back of your fob when buying a replacement; the same car can use two fob designs in one year. A new fob still needs programming to the car.
- Key fob. Trims without push-button start use a key with a remote head that takes a CR1620.
- Roof load. The 176 lb roof limit is the dynamic figure for driving and includes the rack itself. It is not a limit for a rooftop tent when parked; the manual gives no static figure.
- Roof. The limit covers crossbars, carrier and cargo together while driving; the 700 lb figure in the manual applies only when parked.
- Dimensions. Height is for models with roof rails; models without them stand 67.5 inches tall.
